Fire Acts Strangely in Microgravity. Astronauts Have Lit More Than 1,500 Fires on the Space Station to Figure Out Why

Ever since childhood, we were all told to never play with fire. Despite it being relevant to our everyday lives, to include heating our homes and water, cooking our food, producing electricity, and more, fire is extremely dangerous. We were all indoctrinated more with how to put out fires instead of how to start one. We’ve all been told about its destructive properties if mishandled, and that fire needs to be controlled. One of the perks of adulthood, and especially being a scientist, is you get paid to play with fire. Despite fire’s complexities, there’s still a lot we don’t know about its behavior. With more and more of humanity traveling to space and living in microgravity, it’s important to learn about how fire behaves in this unique environment to better prepare ourselves for worst case scenarios. But what if we could also control fire so it’s not as dangerous and less destructive to the environment back here on Earth?

To gain a deeper understanding of combustion phenomena, a team of investigators from academia, NASA’s Glenn Research Center and the agency’s Biological and Physical Sciences Division, and other organizations recently completed a series of investigations on the International Space Station (ISS). The in-orbit testing for the Advanced Combustion via Microgravity Experiments, or ACME, project began in 2017 and included six successful investigations of non-premixed flames of gaseous fuel.

Non-premixed flames are those where the fuel and the oxidizer remain separate before reaction, or ignition, like a candle flame. Premixed flames occur in many of the everyday use scenarios mentioned above, where the fuel and oxidizer are mixed prior to reaction.

“A microgravity environment enables researchers to explore flame behavior without the influence of gravity, so they can investigate the underlying physics behind flame structure and behavior,” said Dennis Stocker, ACME Project Scientist at NASA Glenn. “That knowledge can help designers and engineers here on Earth develop furnaces, power plants, boilers, and other combustion systems that are more efficient, less polluting and safer.”

The six ACME experiments were:

Burning Rate Emulator (BRE) – demonstrated materials can burn for minutes in the absence of air flow in crew vehicle atmospheres being considered for future missions.

Coflow Laminar Diffusion Flame (CLD Flame) – yielded benchmark data at sooty and highly-diluted extremes to improve computational models.

Cool Flames Investigation with Gases (CFI-G) – resulted in non-premixed cool flames of gaseous fuels without enhancements, such as heated reactants, pulsed plasmas, or ozone addition, that have been required in ground testing.

Electric-Field Effects on Laminar Diffusion Flames (E-FIELD Flames) – demonstrated the potential use of electric fields to reduce emissions from non-premixed flames.

Flame Design – demonstrated, for the first time, quasi-steady non-premixed spherical flames, and radiative heat loss leading to extinction for larger flames.

Structure and Response of Spherical Diffusion Flames (s-Flame) – provided data on flame growth and extinction for the improvement of computational models.

The experiments were conducted with a single modular set of hardware in the space station’s Combustion Integrated Rack (CIR). The tests were remotely commanded from NASA’s Glenn ISS Payload Operations Center in Cleveland.

“Over 1,500 flames were ignited, more than three times the number originally planned,” said Stocker. “Several ‘firsts’ were also achieved, perhaps most notably in the areas of cool and spherical flames.”

Stocker said about 50 personnel from NASA Glenn, academia, and ZIN Technologies, Inc. supported ACME during four and a half years of in-orbit operations. In addition, more than 30 crew members from six countries played an essential role in setting up the hardware for each investigation and replacing gas bottles, igniter tips, and other experiment-specific hardware as needed. The ACME hardware has been removed from the CIR to make room for the Solid Fuel Ignition and Extinction, or SoFIE, hardware that launched in February 2022, which is the next step in NASA’s in-orbit combustion research. The ACME hardware is scheduled to return to Earth in the coming months with the intent to launch again to the space station with future experiments.

JAXA astronaut Norishige Kanai reconfigures the High Bit-depth Multispectral (HiBMs) camera within the Combustion Integrated Rack (CIR) for the Electric-Field Effects on Laminar Diffusion Flames (E-FIELD Flames) experiment. (Credits: NASA)


Fire isn’t the only thing that is affected by microgravity, as weightlessness has been long known to cause numerous physiological biochemical changes to the human body, to include bone loss, muscle atrophy, shifting of fluids to the upper extremities, and cardiovascular deconditioning (i.e., changes in the structure of the heart and blood vessels). No one knows about this better than NASA Astronaut Scott Kelly, who spent 340 days in space onboard the ISS starting in March 2015. While his twin brother Mark stayed back on Earth so the two could be studied separately, Scott sent routine samples of his blood, urine, and feces back to Earth via returning astronauts. Scott’s samples showed many genetic changes, to include structural changes to his chromosomes. While 91 percent of Scott’s genes were back to normal after six months back on Earth, nine percent remained in space mode, which included his immune system staying on high alert. His mental abilities had also declined from preflight levels, with short-term and logic tests indicating he was slower and less accurate. This was both an important and historic study since humanity is hoping to send astronauts to Mars in the coming years, and the astronauts will have to spend longer time in weightlessness than Scott did onboard the ISS. The more we can learn about working and living in microgravity, whether it be human or non-human research, the better off future astronauts will be on future missions.

What else will we learn about microgravity as humanity continues to venture farther out into the cosmos? Only time will tell, and this is why we science!

As always, keep doing science & keep looking up!

Sources: NASA, Advances in Space Research, Encyclopedia of Bioastronautics, Science News for Students

Featured Image: Combustion researchers designed experiments on the space station that analyzed the behavior of spherical flames in microgravity. (Credits: NASA)
