Titan Balloon Among Far-Out Concepts NASA Selects For Funding

Article written: 6 Jun , 2014
Updated: 23 Dec , 2015

Sometimes a good idea takes some tinkering. You have a thought that it will work, but what it really requires is you take some money and time and test it out in a small form. This principle is sound if you’re trying to do home renovation (a paint splash on a wall can let you see if the color will work) and it is especially true if you’re planning a multi-million dollar mission to another planet.

This is the thought behind the NASA Innovative Advanced Concepts office, which announced a dozen far-flung drawing-board proposals that received $100,000 in Phase 1 funding for the next 9-12 months. There are vehicles to explore the soupy moon of Titan, a design to snag a tumbling asteroid, and other ideas to explore the solar system. (But be patient: These testbed ideas would take decades to come to fruition, if they are even accepted for further study and funding.)  Check out a full list of the concepts below.

Titan Aerial Daughtercraft: A small rotorcraft that can touch down from a balloon or lander, with the idea being that it can jump between several spots to do close-up views. It would then bring its samples back to the “mothership” and possibly recharge there as well. “The autonomy needed for this concept is also applicable to exciting rotorcraft mission concepts for Mars and to in-situ exploration of Enceladus,” the description stated, referring to an icy moon of Saturn.

Titan SubmarineA small submarine would dive into Kraken Mare on Saturn’s moon, and there would be plenty to explore: 984 feet (300 meters) of depth, stretching across 621 miles (1,000 km). “Kraken Mare is comparable in size to the Great Lakes and represents an opportunity for an unprecedented planetary exploration mission,” the description stated. It would explore “chemical composition of the liquid, surface and subsurface currents, mixing and layering in the ‘water’ column, tides, wind and waves, bathymetry, and bottom features and composition.”

Comet Hitchhiker: This would be a “tethered” spacecraft that swings from comet to comet to explore icy bodies in the solar system. “First, the spacecraft harpoons a target as it makes a close flyby in order to attach a tether to the target. Then, as the target moves away, it reels out the tether while applying regenerative brake to give itself a moderate (<5g) acceleration as well as to harvest energy,” the description stated.

Artist's conception of  the Weightless Rendezvous And Net Grapple to Limit Excess Rotation (WRANGLER). Credit: NASA

Artist’s conception of the Weightless Rendezvous And Net Grapple to Limit Excess Rotation (WRANGLER). Credit: NASA

Weightless Rendezvous And Net Grapple to Limit Excess Rotation (WRANGLER): This idea would capture space debris and small asteroids. It will use a small nanosatellite equipped with a “net capture device” and a winch. “The leverage offered by using a tether to extract angular momentum from a rotating space object enables a very small nanosatellite system to de-spin a very massive asteroid or large spacecraft,” the description stated.

The Aragoscope: A telescope that would look through an opaque disk at a distant object, which is different from the usual mirror arrangement.”Rather than block the view, the disk boosts the resolution of the system with no loss of collecting area,” the description states. This architecture … can be used to achieve the diffraction limit based on the size of the low cost disk, rather than the high cost telescope mirror.”

Mars Ecopoiesis Test Bed: A machine that would test how well bacteria from Earth could survive on Mars, which could be a precursor to “terraforming” the planet to make it more like our own. Researchers would select “pioneer organisms” and put them into a device that would embed itself into the Martian regolith (soil) in an area that would have liquid water. It would “completely seal itself to avoid planetary contamination, release carefully selected earth organisms (extremophiles like certain cyanobacteria), sense the presence or absence of a metabolic product (like O2), and report to a Mars-orbiting relay satellite,” the description states.

Artist's conception of ChipSats. Credit: NASA

Artist’s conception of ChipSats. Credit: NASA

ChipSats: Instead of having an orbiter and a lander in separate missions, why not put them in one? While there have been combinations before (e.g. Cassini/Huygens), this is a bit different: This concept would have a set of tiny sensor chips (ChipSats) that deploy from a larger mothership to make a landing on a distant planet or moon.

Swarm Flyby Gravimetry: While whizzing by a comet or asteroid, a single spacecraft would release a swarm of tiny probes. “By tracking those probes, we can estimate the asteroid’s gravity field and infer its underlying composition and structure,” the description stated.

Probing icy worlds concept: How thick is the ice on Jupiter’s Europa or Ganymede, or Saturn’s Enceladus? Open question, and makes it hard to predict how tough of a drill one would need to probe the ice — or how well life could survive. This concept would send a probe to one of these locations and receive “a naturally occurring signal generated by interactions of deep penetrating cosmic ray neutrinos” to better get a sense of the depth. This could allow for maps of the ice.

The cracked ice surface of Europa. Credit: NASA/JPL

The cracked ice surface of Europa. Credit: NASA/JPL

Heliopause Electrostatic Rapid Transit System (HERTS): This would be a mission that goes deep into the solar-system and out to the heliopause, the spot where the sun’s sphere of influence gives way to the interstellar medium. Using no propellant, the spacecraft would use solar wind protons to bring it out into the solar system. “The propulsion system consists of an array of electrically biased wires that extend outward 10 to 30 km [6.2 miles to 18.6 miles] from a rotating spacecraft,” the researchers stated.

3D Photocatalytic Air Processor: A new design to make it easier to generate oxygen on a spacecraft, using “abundant high-energy light in space,” the proposal states. ” The combination of novel photoelectrochemistry and 3-dimensional design allows tremendous mass saving, hardware complexity reduction, increases in deployment flexibility and removal efficiency.”

PERIapsis Subsurface Cave OPtical Explorer (PERISCOPE)A way to probe caves on the moon from orbit. Using a concept called “photon time-of-flight imaging”, the researchers say they would be able to bounce the signal off of the walls of the canyon to peer into the crevice and see what is there.
