Mysterious Arc of Light Spotted with Spitzer Telescope

Article written: 26 Jun , 2012
Updated: 23 Dec , 2015

From a JPL press release:

Seeing is believing, except when you don’t believe what you see. Astronomers using NASA’s Hubble Space Telescope have found a puzzling arc of light behind an extremely massive cluster of galaxies residing 10 billion light-years away. The galactic grouping, discovered by NASA’s Spitzer Space Telescope, was observed as it existed when the universe was roughly a quarter of its current age of 13.7 billion years.

The giant arc is the stretched shape of a more distant galaxy whose light is distorted by the monster cluster’s powerful gravity, an effect called gravitational lensing. The trouble is, the arc shouldn’t exist.

“When I first saw it, I kept staring at it, thinking it would go away,” said study leader Anthony Gonzalez of the University of Florida in Gainesville, whose team includes researchers from NASA’s Jet Propulsion Laboratory, Pasadena, Calif. “According to a statistical analysis, arcs should be extremely rare at that distance. At that early epoch, the expectation is that there are not enough galaxies behind the cluster bright enough to be seen, even if they were ‘lensed,’ or distorted by the cluster. The other problem is that galaxy clusters become less massive the further back in time you go. So it’s more difficult to find a cluster with enough mass to be a good lens for gravitationally bending the light from a distant galaxy.”

Galaxy clusters are collections of hundreds to thousands of galaxies bound together by gravity. They are the most massive structures in our universe. Astronomers frequently study galaxy clusters to look for faraway, magnified galaxies behind them that would otherwise be too dim to see with telescopes. Many such gravitationally lensed galaxies have been found behind galaxy clusters closer to Earth.

The surprise in this Hubble observation is spotting a galaxy lensed by an extremely distant cluster. Dubbed IDCS J1426.5+3508, the cluster is the most massive found at that epoch, weighing as much as 500 trillion suns. It is 5 to 10 times larger than other clusters found at such an early time in the history of the universe. The team spotted the cluster in a search using NASA’s Spitzer Space Telescope in combination with archival optical images taken as part of the National Optical Astronomy Observatory’s Deep Wide Field Survey at the Kitt Peak National Observatory, Tucson, Ariz. The combined images allowed them to see the cluster as a grouping of very red galaxies, indicating they are far away.

This unique system constitutes the most distant cluster known to “host” a giant gravitationally lensed arc. Finding this ancient gravitational arc may yield insight into how, during the first moments after the Big Bang, conditions were set up for the growth of hefty clusters in the early universe.

The arc was spotted in optical images of the cluster taken in 2010 by Hubble’s Advanced Camera for Surveys. The infrared capabilities of Hubble’s Wide Field Camera 3 helped provide a precise distance, confirming it to be one of the farthest clusters yet discovered.

Once the astronomers determined the cluster’s distance, they used Hubble, the Combined Array for Research in Millimeter-wave Astronomy (CARMA) radio telescope, and NASA’s Chandra X-ray Observatory to independently show that the galactic grouping is extremely massive.

“The chance of finding such a gigantic cluster so early in the universe was less than one percent in the small area we surveyed,” said team member Mark Brodwin of the University of Missouri-Kansas City. “It shares an evolutionary path with some of the most massive clusters we see today, including the Coma cluster and the recently discovered El Gordo cluster.”

An analysis of the arc revealed that the lensed object is a star-forming galaxy that existed 10 billion to 13 billion years ago. The team hopes to use Hubble again to obtain a more accurate distance to the lensed galaxy.

The team’s results are described in three papers, which will appear online today and will be published in the July 10, 2012 issue of The Astrophysical Journal. Gonzalez is the first author on one of the papers; Brodwin, on another; and Adam Stanford of the University of California at Davis, on the third. Daniel Stern and Peter Eisenhardt of JPL are co-authors on all three papers.

Lead image caption: These images, taken by NASA’s Hubble Space Telescope, show an arc of blue light behind an extremely massive cluster of galaxies residing 10 billion light-years away. Image credit: NASA/ESA/University of Florida, Gainsville/University of Missouri-Kansas City/UC Davis

, ,

10 Responses

  1. Member
  2. Boone_1781 says

    This is major! ;^) That is going to be one young galaxy that is already a pretty good size…

  3. Torbjörn Larsson says

    That was hard going.

    I take it from the papers that the galaxy mass itself falls well within the LCDM model (“we were simply somewhat lucky”, p5 “SZ Measurement…”). So the standard cosmology has no problem out of this.

    But the arc is problematic to resolve.

    The only realistic resolution was that the dark matter halo concentration is higher than expected. The current distribution for that is a heuristic derived from simulations. To correctly predict local halos, the early halo concentration goes down compared to earlier heuristics.

    So the largest tension seems to be with the current state of the art in predicting dark matter behavior. That doesn’t seem too bad, should be exciting for those who work the area.

  4. newSteveZodiac says

    You have to read this very carefuly to distinguish which is the lensed and which is the lensing galaxy. My less informed response is 1) why is the light blue? 2) Why is the lensed assumed to be a galaxy – is it the spectrum? 3) would an early enough galaxy lens the BB afterglow light?

    • magnus.nyborg says

      I can answer your question #1.
      The light is not really blue. This is Spitzer imaging, and Spitzer image only in infrared, so one of the infrared channels was assigned blue for the image.

      • newSteveZodiac says

        “The arc was spotted in optical images of the cluster taken in 2010 by Hubble’s Advanced Camera for Surveys” and on the ACS website it says
        “ACS sees in wavelengths from the far ultraviolet to visible light, making it capable of studying some of the earliest activity in the universe.” although the diagram on does show it reaching into parts of the IR spectrum so I am none the wiser

      • magnus.nyborg says

        Aaah, you are correct.
        My guess then would be active starforming regions, boy do I want JWT to launch.

    • Boone_1781 says

      I’m not sure about the blue. It might be because it’s lensed – magnified? Or maybe magnus below is right. 😉

      It’s identified as a galaxy apparently because it maps to a galaxy shape… or it may simply take an “extended object” to be lensed in such a well-shaped arc…

      But yes, in the early press release, it was hard to tell which they were more excited about – the arc or the cluster at z=1.75

  5. Member
    Aqua4U says

    An arc? What I see looks more like 4 images of the same object?

    • DrFlimmer says

      I assume that’s due to the resolution of the picture. You might notice the “noise” in the picture. I’m quite sure that’s the reason for having “4” images instead of 1 arc, which it certainly is.
