New Map Hints at Venus’ Wet, Volcanic Past

Article written: 14 Jul , 2009
Updated: 24 Dec , 2015
by

[/caption]
Venus is often referred to as Earth’s twin, as the two planets share a similar size. But perhaps the similarities don’t end there. A new infrared map from Venus Express hints that our neighboring world may once have been more Earth-like, with a plate tectonics system and an ocean of water. While previous radar images have given us a glimpse of Venus’ cloud-shrouded surface, this is the first map that hints at the chemical composition of the rocks. The new data are consistent with suspicions that the highland plateaus of Venus are ancient continents, once surrounded by ocean and produced by past volcanic activity.

“This is not proof, but it is consistent. All we can really say at the moment is that the plateau rocks look different from elsewhere,” says Nils Müller at the Joint Planetary Interior Physics Research Group of the University Münster and DLR Berlin, who headed the mapping efforts.

The first temperature map of the planet's southern hemisphere at infrared wavelengths, charted with Venus Express's Visible and Infrared Thermal Imaging Spectrometer, VIRTIS. Credits: ESA/VIRTIS/INAF-IASF/Obs. de Paris-LESIA

The first temperature map of the planet's southern hemisphere at infrared wavelengths, charted with Venus Express's Visible and Infrared Thermal Imaging Spectrometer, VIRTIS. Credits: ESA/VIRTIS/INAF-IASF/Obs. de Paris-LESIA


The map shows Venus’ southern hemisphere comprised over a thousand individual images, recorded between May 2006 and December 2007. The Visible and Infrared Thermal Imaging Spectrometer (VIRTIS) instrument captured infrared radiation given off by the various surfaces on Venus during the spacecraft’s night-time orbits around the planet’s southern hemisphere.

Different types of rocks radiate different amounts of heat at infrared wavelengths owing to a material characteristic known as emissivity. The new map shows that the rocks on the Phoebe and Alpha Regio plateaus are lighter in color and look old compared to the majority of the planet. On Earth, such light-colored rocks are usually granite and form continents.

“If there is granite on Venus, there must have been an ocean and plate tectonics in the past,” says Müller.
Granite is formed when ancient rocks, made of basalt, are driven down into the planet by shifting continents, a process known as plate tectonics. The water combines with the basalt to form granite and the mixture is reborn through volcanic eruptions.

Müller points out that the only way to know for sure whether the highland plateaus are continents is to send a lander there. Over time, Venus’ water has been lost to space, but there might still be volcanic activity. The infrared observations are very sensitive to temperature. But in all images they saw variations of only 3–20°C, instead of the kind of temperature difference they would expect from active lava flows.

“Venus is a big planet, being heated by radioactive elements in its interior. It should have as much volcanic activity as Earth,” he says. Indeed, some areas do appear to be composed of darker rock, which hints at relatively recent volcanic flows.

Lead image caption: Artistic interpretation of a possible volcano on Venus. Credits: ESA – AOES Medialab

Source: ESA
