How a Hubble Image Goes from Photons to Finished Beauty

Arp 274 is a trio of galaxies. They appear to be partially overlapping in this image, but may be located at different distances. Credit: NASA, ESA, M. Livio and the Hubble Heritage Team (STScI/AURA)

Arp 274 is a trio of galaxies. They appear to be partially overlapping in this image, but may be located at different distances. Credit: NASA, ESA, M. Livio and the Hubble Heritage Team (STScI/AURA)

How does raw data from the Hubble Space Telescope end up to become a finished gorgeous color image, like the one of Arp 274, above? It’s an interesting process, because the cameras on Hubble do not take color pictures.

The Hubble team released a video today showing the process of creating an image of Arp 274:

Color images from the spacecraft are assembled from separate black & white images taken through color filters. For one image, the spacecraft has to take three pictures, usually through a red, a green, and a blue filter and then each of those photos gets downlinked to Earth. They are then combined with software into a color image. This happens automatically inside off-the-shelf color cameras that we use here on Earth. But Hubble has almost 40 color filters ranging from ultraviolet (“bluer” than our eyes can see,) through the visible spectrum, to infrared (“redder” than what is visible to humans.) This gives the imaging teams infinitely more flexibility, allowing them to eke out whatever science information they are looking for, as well as, sometimes, allowing them to take a little artistic license.

You can read our previous article about “true and false color” and the art of extraterrestrial photography.

About

Nancy Atkinson is Universe Today's Senior Editor. She also works with Astronomy Cast, and is a NASA/JPL Solar System Ambassador.

Comments on this entry are closed.

  • Aqua4U June 7, 2013, 11:15 PM

    RGB it is! When the cosmic ray streaks and dots are removed, how can they tell which of the ‘dots’ aren’t foreground stars or background galaxies? Those that appear in every image? I wonder how many supernova have been ‘accidentally’ removed?

    • Steven Coates June 7, 2013, 6:32 PM

      The foreground stars are “fixed” where cosmic rays are random. Stacking programs (DeepSkyStacker, MaximDL, PixInsight etc. can run an algorithm to remove the random cosmic ray.

    • IVAN3MAN_AT_LARGE June 8, 2013, 12:13 AM

      Foreground stars, and therefore bright objects, tend to produce diffraction spikes.

  • czarnajama June 8, 2013, 8:17 PM

    The median of a set of images eliminates the transient cosmic ray “flashes”. Also, the output RGB colors don’t have to correspond to the observed wavelengths, hence the term “false color image”. Foreground stars can be recognized by their brightnesses and colors, and if necessary, by the Doppler shifts of their spectra (indicating speeds along the line of sight very different from those of the galaxies).

  • Planemo June 9, 2013, 3:09 AM

    It is just so beautiful.

  • Planemo June 9, 2013, 4:01 PM

    So another words it is like photoshop or airbrushed, etc.. . I thought x-ray’s and the other etc’s took care of that. Don’t tell me “thought” screwed up again! If thats the case, I gotta get him outta my head…lol.
