New Image of Jet-Driven Galactic Shock Wave is a Shocker

Article written: 23 Apr , 2009
Updated: 24 Dec , 2015
by

[/caption]
The Chandra X-ray observatory has taken a closer look at the galaxy Centaurus A, and new images have revealed in detail the effects of a shock wave blasting through the galaxy. Powerful jets of plasma emanating from a supermassive black hole at the galactic core are creating the shock wave, and the new observation, have enabled astronomers to revise dramatically their picture of how jets affect the galaxies in which they live.

A team led by Dr. Judith Croston from the University of Hertfordshire and Dr. Ralph Kraft, of the Harvard-Smithsonian Center for Astrophysics used very deep X-ray observations from Chandra to get a new view of the jets in Centaurus A. The jets inflate large bubbles filled with energetic particles, driving a shock wave through the stars and gas of the surrounding galaxy. By analyzing in detail the X-ray emission produced where the supersonically expanding bubble collides with the surrounding galaxy, the team were able to show for the first time that particles are being accelerated to very high energies at the shock front, causing them to produce intense X-ray and gamma-ray radiation. Very high-energy gamma-ray radiation was recently detected from Centaurus A for the first time by another team of researchers using the High Energy Stereoscopic System (HESS) telescope in Namibia.

“Although we expect that galaxies with these shock waves are common in the Universe, Centaurus A is the only one close enough to study in such detail,” said Croston. “By understanding the impact that the jet has on the galaxy, its gas and stars, we can hope to understand how important the shock waves are for the life cycles of other, more distant galaxies.”

Centaurus A (NGC 5128) is one of our closest galactic neighbors, and is located in the southern constellation of Centaurus. The supermassive black hole is the source of strong radio and X-ray emissions. Visible in the image below, (click here for a zoomable image from Chandra) a combined image from Chandra and the Atacama Pathfinder Experiment (APEX) telescope in Chile, is a dust ring encircling the giant galaxy, and the fast-moving radio jets ejected from the galaxy center.

Centaurus A. Credit: ESO/WFI (Optical); MPIfR/ESO/APEX/A.Weiss et al. (Submillimetre); NASA/CXC/CfA/R.Kraft et al. (X-ray)

Centaurus A. Credit: ESO/WFI (Optical); MPIfR/ESO/APEX/A.Weiss et al. (Submillimetre); NASA/CXC/CfA/R.Kraft et al. (X-ray)

The powerful jets are found in only a small fraction of galaxies but are most common in the largest galaxies, which are thought to have the biggest black holes. The jets are believed to be produced near to a central supermassive black hole, and travel close to the speed of light for distances of up to hundreds of thousands of light years. Recent progress in understanding how galaxies evolve suggests that these jet-driven bubbles, called radio lobes, may play an important part in the life cycle of the largest galaxies in the Universe.

Energetic particles from radio galaxies may also reach us directly as cosmic rays hitting the Earth’s atmosphere. Centaurus A is thought to produce many of the highest energy cosmic rays that arrive at the Earth. The team believes that their results are important for understanding how such high-energy particles are produced in galaxies as well as for understanding how massive galaxies evolve.

The results of this research will be published in a forthcoming issue of the Monthly Notices of the Royal Astronomical Society and were presented at the European Week of Astronomy and Space Science in the UK.

Source: RAS
