Journey Inside A Bok Globule


You asked for more? You got it. This time our dimensional visualization is going to take us 9500 light years away from where you’re sitting now and deep into the Perseus spiral arm of the Milky Way Galaxy. Buckle your seat belt and relax your eyes, because we’re heading into two versions of a 132 light year expanse known as NGC 281 and the central core called IC 1590…

Just like last time, this dual image requires a little bit of a challenge on your part to create a 3D effect. Thanks to the wizardry of Jukka Metsavainio, we’ve gone even one better. There’s two! The first version you see on this page are for those of you who have success relaxing your eyes and being a certain distance from the screen to get the images to merge. The one below is for those of you who have better luck crossing your eyes and catching dimension in the center image. Are you ready for your journey? Then have a look and let’s learn…

NGC281/IC1590 Hubble Heritage Cross Vision - Jukka Metsavainio
NGC281/IC1590 Hubble Heritage Cross Vision - Jukka Metsavainio

The whole gigantic region of nebulosity is known as NGC 281 and most commonly referred to as the “Pac Man Nebula”. Visible to small telescopes and located in the constellation of Cassiopeia (RA 00:42:59.35 Dec +56:37.18.8), this cloud of high density hydrogen gas is being ionized by an incredible output of ultraviolet radiation from the hot, neophyte stars which coalesced there. Deep in the center of this HII region is a open area called IC 1590 – home to a young galactic star cluster – and several dark patches known as “Bok Globules”.

If that sounds like something you might expel when you have a cold, you’re right. They are cold… Cold pockets of dense dust, molecular hydrogen and gas. Bok globules are the brain child of astronomer Dr. Bart Jan Bok – who, among other things, loved to study the paranormal. When Bok proposed their existence in the 1940’s, he knew what was going on. These dark regions were acting like interstellar cocoons – protecting their inner stars from being stripped by the radioactive stellar winds of nearby companions and blocking visible light. When stellar metamorphosis had occurred, the new star then begins to send out its own winds and radiation to evaporate the globule – but this isn’t always the case. Sometimes the cocoon gets destroyed before the life inside ignites.

In our image you will see bright blue stars, members of the young open cluster IC 1590, near the globules. Meanwhile, the cluster’s partially revealed core in the upper right hand corner is filled with a tight grouping of extremely hot, massive stars emitting visible and ultraviolet light, causing those incredible pink clouds. When these star forming dust clouds were first imaged by Hubble, we thought we knew a lot about them. But what have we learned since?

According to research done by T.H. Henning (et al): “The exciting star HD 5005 of the optical nebulosity is a Trapezium system… and emission shows that the molecular cloud NGC 281 A consists of two cloud fragments. The western fragment is more compact and massive than the eastern fragment and contains an NH3 core. This core is associated with the IRAS source 00494+5617, an H2O maser, and 1.3 millimeter dust continuum radiation. Both cloud fragments contain altogether 22 IRAS point sources which mostly share the properties of young stellar objects. The maxima of the 60 and 100 micrometers HIRES maps correspond to the maxima of the (12)CO (3 to 2) emission. The NGC 281 A region shares many properties with the Orion Trapezium-BN/KL region the main differences being a larger separation between the cluster centroid and the new site of star formation as well as a lower mass and luminosity of the molecular cloud and the infrared cluster.”

Great! It’s confirmed! It’s a star forming region, very much like what we can observe when we see M42. But, maybe… Maybe there’s just a little bit more to it than that? Hubble observations shows the jagged structure of the dust clouds as if they are being stripped apart from the outside. What could have caused that? Only the radiation from the nearby stars? Hmmm…. Not everyone seems to think so.

A 2007 study done by Mayumi Sato (et al) states: “Our new results provide the most direct evidence that the gas in the NGC 281 region was blown out from the Galactic plane, most likely in a superbubble driven by multiple or sequential supernova explosions in the Galactic plane.” Supernova? Yeah, you bet. And someone else thinks so, too…

Says S.T. Megeath (et al): “We suggest that the ring has formed in a superbubble blowout driven by OB stars in the plane of the Galaxy. Within the cloud complex, combined optical, NIR, mm and cm data detailing the interaction of a young O star with neighboring molecular cores, provide evidence of triggered star formation inside the cloud complex on a few parsec scale. These data suggest that two modes of triggered star formation are operating in the NGC 281 complex – the initial supernovae triggered formation of the entire complex and, after the first generation of O stars formed, the subsequent triggering of star formation by photoevaporation-driven molecular core compression.”

You’ve got it. This type of research suggests the cores were created within the molecular cloud. When they were exposed to direct UV radiation, the low density gas was stripped. This increase in pressure then caused a rippling shockwave which triggered star formation – first in the compressed regions and then in the HII areas. Says Megeath, “The total kinetic energy of the ring requires the energy of multiple supernovae. Both the high Galactic latitude and large expansion velocity may be explained if the NGC 281 complex originated in the blowout of an expanding superbubble. The loop of HI seen extending from the Galactic plane may trace the edge of a superbubble powered by supernovae near the Galactic plane. The expansion of a superbubble into the increasingly rarefied Galactic atmosphere can lead to a runaway expansion of the shell and the blowout of the bubble into the Galactic atmosphere. NGC 281 could have formed in the gas swept up and compressed in a blowout. Hence, NGC 281 maybe an example of the supernovae-driven formation of molecular clouds (and consequently, supernovae-triggered star formation).”

What incredible region! Hope you enjoyed your journey… And be sure to tip your hat to Bart Jan Bok who told the IAU (when they named Asteroid Bok for him in 1983) “Thanks for a little plot of land that I can retire to and live on.”

Our many, many thanks to Jukka Metsavainio of Northern Galactic for creating this unique image for Universe Today Readers! We look forward to more…
