A Tale of Three Moons: Is There Life in the Outer Solar System?

Article written: 18 Oct , 2011
Updated: 24 Dec , 2015
by

[/caption]

Until fairly recently, the search for life elsewhere in the solar system has focused primarily on Mars, as it is the most Earth-like of all the other planets in the solar system. The possibility of finding any kind of life farther out in the outer solar system was considered very unlikely at best; too cold, too little sunlight, no solid surfaces on the gas giants and no atmospheres to speak of on any of the moons apart from Titan.

But now, some of the places that were previously considered the least likely to hold life have turned out to be perhaps some of the most likely to provide habitable environments. Moons that were thought be cold and frozen for eons are now known to be geologically active, in surprising ways. One of them is the most volcanically active place known in the solar system. At least two others appear to have oceans of liquid water beneath their surfaces. That’s right, oceans. And geysers. On the surface, they are ice worlds, but below, they are water worlds. Then there’s the one with rain, rivers, lakes and seas, but made of liquid methane instead of water. Billions of kilometres farther out from the Sun than the Earth. Who would have thought? Let’s look at those last three in a bit more detail…

Ever since the film 2001: A Space Odyssey first came out, Europa has been the subject of fascination. A small, icy moon orbiting Jupiter, its depiction in that movie, as an inhabited world beneath its ice crust was like a sort of foreshadowing, before the Voyager and Galileo spacecraft gave us our first real close-up looks of this intriguing place. Its surface shell of ice is covered with long cracks and fissures, giving it an appearance much like ice floes at the poles on Earth. More surprising though, was the discovery that, also like on Earth, this ice cover most likely is floating on top of a deep layer of liquid water below. In Europa’s case though, the water layer appears to cover the entire moon, a global subsurface ocean. How is this possible? If there is liquid water, there must be heat (or high concentrations of salts or ammonia), and if you have water and heat, could there be something living in those waters? Gravitational tugging from Jupiter indeed appears to provide enough heat to keep the water liquid instead of frozen. The environment is now thought to be similar to ocean bottoms on Earth. No sunlight, but if there are volcanic vents generating heat and minerals, as on Earth, such a spot could be ideal for at least simple forms of life. On Earth, places like these deep in the oceans are brimming with organisms which don’t require sunlight to survive.

Water vapour geysers on Enceladus. Credit: NASA/JPL

Then there’s Enceladus. Another very small icy moon, orbiting Saturn. Geological activity was considered very unlikely on such a tiny world, only a few hundred kilometres in diameter. But then Cassini saw the geysers, plumes of material erupting from the south polar region through large, warmer cracks nicknamed “tiger stripes.” Cassini has now flown directly through the geysers, analyzing their composition, which is mostly water vapour, ice particles, salts and organics. The latest analysis based on the Cassini data indicates that they almost certainly originate from a sea or ocean of liquid water below the surface. Warm, salty water loaded with organics; could Enceladus be another possible niche for extraterrestrial life? As with Europa, only further missions will be able to answer these questions, but the possibilities are exciting.

Radar image of one of many methane lakes on Titan. Credit: NASA/JPL

Titan is even more fascinating in some ways, the largest moon of Saturn. It is perpetually shrouded in a thick smoggy atmosphere of nitrogen and methane, so the surface has never been visible until now, when Cassini, and its small lander probe Huygens, first looked below the smog and clouds. Titan is like an eerily alien version of Earth, with rain, rivers, lakes and seas, but being far too cold for liquid water (not much heat here), its “water cycle” is composed of liquid methane/ethane. Appearance-wise, the surface and geology look amazingly Earth-like, but the conditions are uniquely Titan. For that reason, it has long been considered that the chances of any kind of life existing here are remote at best. In the last few years however, some scientists are starting to consider the possibility of life forming in just such environments, using liquids other than water, even in such cold conditions. Could life occur in a liquid methane lake or sea? How would it differ from water-based life? Last year, a discovery was made which might be interpreted as evidence of methane-based life on Titan – a seeming disappearance of hydrogen from the atmosphere near the surface and a lack of acetylene on the surface. Previous theoretical studies had suggested that those two things, if ever found, could be evidence for methane-based lifeforms consuming the hydrogen and acetylene. All of this is still highly speculative, and while a chemical explanation is probably more likely according to the scientists involved, a biological one cannot be ruled out yet. Future proposed missions for Titan include a floating probe to land in one of the lakes and a balloon to soar over the landscape, pursuing such mysteries as never before. How cool is that?

Oh, and the moon that is the most volcanically active place in the solar system? Io, although with the only known forms of liquid there being extremely hot lavas on that sulfuric hothouse, the chances of life are still thought to be unbelievably slim. But that’s ok when you start to find out that worlds with oceans and lakes, etc. may be much more common than previously imagined…

, , ,



10 Responses

  1. I remember borrowing a book about planets from the school library in the late eighties, in which the author speculated that Titan might be the place where life could be found. However, there the speculation was that Titan might be warm enough to support life thanks to a runaway greenhouse effect like that on Venus.

  2. Anonymous says

    “Ever since the film 2001: A Space Odyssey first came out, Europa has been the subject of fascination.” Actually, Europa was featured in “2010” the sequel. “All these worlds are yours, except Europa. Attempt no landings there. Use them together, use them in peace,” was the message sent by the black monolith. Yeah, I may have watched that movie just a few too many times. :-}

  3. IVAN3MAN_AT_LARGE says

    Future proposed missions for Titan include a floating probe to land in one of the lakes and and a balloon to soar over the landscape, pursuing such mysteries as never before. How cool is that?

    About 93.7 K.

    P.S. There’s a double instance of the conjunction “and” in the last sentence of the penultimate paragraph: “[…] in one of the lakes and and a balloon […]”

  4. squidgeny says

    Great article.

  5. Anonymous says

    I suppose I have to raise questions with the conjecture about life on these moons. The main ingredient for self-replicating chemical processes is the continual input of heat energy. The first law of thermodynamics is change in thermal energy = change in kinetic energy (E) plus change in internal energy (U)

    dQ = dE + dU

    where dE = pdV and the thermal energy change is dQ = TdS and the internal energy is due to the equipartition of energy amongst N particles dU = NkdT + ?dN. The full equation is then

    TdS = pdV + NkdT + ?dN.

    For the gas or system with a specific heat C we have the change in entropy dS = CdT. For the sake of argument we ignore the chemical potential term ?dN. So the work which can be performed on a system is

    dE = pdV = (CT – Nk)dT

    which relies upon a heat flow with a temperature different dT > 0. Also the temperature has to be such that CT > Nk and be large enough to give a significant dE.

    Clearly for these moons, the Jovian moons at around liquid nitrogen temperatures ~ 150K and the Saturnian moon at around 100K, there are sufficient temperature changes to drive these geological processes. The question is whether there is enough to drive something similar to life. The ATP + polypeptide — > ADP + polypeptide-P is basic to the energetics of biochemical pathways. ATP hydrolysis is the reaction by which chemical energy that has been stored and transported in the phosphoanhydridic bonds in ATP This involves a dQ per mole of 76kcal/mol. The Joule equivalent between mechanical energy and heat is 4.2 J•g-1•°C-1, which is. So for a mole of ATP this is about 10^6 joules/mole. For a micromole of ATP per mole of water (molarity = 10^{-6}) compute the temperature change this would induce on a mole of water using

    ?U = Nk?T == > 1 = 6.02×10^{23}x1.38×10^{-23}j/K ?T

    so ?T ~ .1K. This means there must be enough heat flow so there is this amount of internal energy due to ATP hydrolysis. This is within one gram of water. The heat flow must be larger than this, or the temperature difference across one gram of water must be larger.

    This is a rather problematic assumption. At the low temperatures on these moons there may not be the sorts of heat gradients required to provide the heat energy flows required. The geysers on Europa may be driven by 100K temperature differences across kilometers of ice mantle. The question is whether the energy flow is sufficient to create ~1K temperature gradients across a few grams of material.

    LC

    • IVAN3MAN_AT_LARGE says

      The next time some creationist twat says that evolution is impossible because it violates the second law of thermodynamics, I’m gonna confuse him with your equations!

      • Anonymous says

        The creationist argument against evolution based on thermodynamics does imply that life itself is impossible. I suppose in the end it is in their interest to abolish biology as a subject which studies the natural processes of life, and replace that with some élan vitale or divine principle.

        I watched the NOVA program last night. I suppose the one thing which can be done to test these hypotheses about life on these ice moons is to, as Squires suggested, to fly a probe through the plumes emitted by the fissures on Enceladus. If there is life on Enceladus it could be captured pretty easily and returned to Earth in a cryro-dewar on a small return capsule. This is economically more reasonable than trying to drill down below the ice crust of Europa.

        I still say that Mars is the best shot for finding life outside Earth. Mars has an average temperature of dry ice, which is pretty cold, but does permit liquid to exist in sub-regolith regions. The little water flows seen coming out of crater rims pretty clearly clinches the existence of liquid water. In this sub-regolith region there might exist a microbial ecosystem.

        LC

      • IVAN3MAN_AT_LARGE says

        I agree; I’m betting on subterranean life being found on Mars.

  6. Torbjörn Larsson says

    Great to have Anderson/Meridiani Journal here, and the good writing shows!

    The latest scuttlebutt on Enceladus would be, for us reading laymen, that large salt crystals in the center of the plumes would be difficult to explain _without_ a salty ocean (reversing the burden of proof) and that observations of plume ice deposit’s rates and thicknesses certify at least 100 Ma liquid water lifetime, likely continuously so.

    That should be enough for life…

    ——————
    My “but” point used to be the absence of organic metabolic patterns (consumption/production) in the plume organics, which looks cometary pristine. But later models say the ocean melts overlaying ice and some or almost all of the plume material originates there.

    So today I think this place is a cellular… excuse me, _singular_, opportunity to get to some interesting extraterrestrial liquids.
