Astrophotography: NGC 3718 by Dietmar Hager

Article written: 21 Apr , 2008
Updated: 24 Dec , 2015

If southern skies stargazers thought there was nothing to the north to be interested in, then think again. There’s a surprising number of galaxies both close to home and towards the farthest reaches of our Universe in the constellation of Ursa Major. It you think the larger of this 42 million light year distant galactic pair is a little warped, you’d be right. But there’s more than two cosmic cannibals in this astronomy picture.

Originally discovered by Sir William Herschel during this very same month 211 years ago, NGC 3718 became the future study of an astronomer named Halton Arp. For 28 years Dr. Arp was staff astronomer at the Mt. Palomar and Mt. Wilson observatories and while there, he produced his well known catalog of Peculiar Galaxies that are disturbed or irregular in appearance. Needless to say, NGC 3718 became Arp 214: “”Barred spiral, (with a) sharp nucleus, narrow absorption lanes through center”.

But it’s not quiet and it’s alone in the field. Joining warped NGC 3718 around 150,000 light years away is NGC 3729 – another massive galaxy which may be causing its neighbor’s peculiarities. While the warping of galactic discs is common, the process is not quite yet understood. It’s highly possible that tidal forces exerted by neighboring galaxies could be at work and in the case of this pair, it seems to carry through.

NGC 3718 contains an active galactic nucleus (AGN) and is known as a Seyfert Galaxy type 1.9 – one which may contain a massive black hole and is known for violent stars. Through HI mapping, NGC 3718 displays a tidal “tail” which begins on its eastern frontier and extends north towards its companion, NGC 3729. Is this just a case gravitational relationship? One galaxy consuming another? Let’s find out…

It is commonly accepted that when galaxies pass each other that tidal forces draw out the companion galaxy’s stars, gas, and dust in the formation of a spectacular tail. Just as it is commonly accepted that a merger of two spiral galaxies results in a remnant with an elliptical-like surface-brightness profile. In the case of NGC 3718, it would appear (according to interferometer data), the disk warp is evolving into a polar ring. No doubt, its molecular gas content is consistent with elliptical galaxy structure, but the distribution is warping the inner disk. At the same time, 2MASS data shows Arp 214’s main support against gravitational collapse comes from pressure due to random motion of stars as seen in an elliptical galaxy rather than from rotation. The origin of the unusual combination of properties makes the whole scene not only beautiful to look at, but most unique.

But don’t stop there… A closer examination of this picture will also show another another compact set of interacting galaxies as well – Hickson 56. Instead of two, there are five which share similarities with the closer cousins. Located some 400 million light years distant, this Hickson compact group has several catalogue designations including UGC 6527, VV 150, Markarian 176 and Arp 322 and were originally observed by Lord Rosse. According to Halton Arp, “Much print has been dedicated to explaining discordant redshifts in compact groups as unrelated background galaxies. But no one has analyzed the accordant galaxies. It is shown here that when there is a brightest galaxy in the group, the remainder with differences of less than 1000 km s−1 are systematically redshifted. This is the same result as obtained in all other well-defined groups and demonstrates again an increasing intrinsic redshift with fainter luminosity.”

So what’s Paul Hickson take? “Group 56 consists of five galaxies, three of which appear to be in contract and interacting. Two of these three galaxies (B and D) are <a href=””radio source galaxies. Infrared emission is also detected from this interacting system.” Much like it’s closer counterpart, Hickson 56 displays a notable stream of “galaxy stuff” linking its B and C components. An examination of the C galaxy reveals an asymmetric halo but D has a less complex outer luminosity profile. Last, but not least, both the A and D galaxies are Seyfert. More galaxies that have – or are – interacting in the past, present and future.

What’s the chances of seeing some these galaxies yourself? Not bad at all. For the average-to-large telescope, NGC 3718 (RA 11 32 56 Dec +53 01 55) is roughly magnitude 10 to 11 (depending on whose scale you’re looking at) and is noted as a soft, even haze with a dark dustlane seen upon aversion. NGC 3729 (RA 11 34 Dec +53 08), despite its magnitude billing is low surface brightness and requires a large telescope and aversion to detect. As for Hickson 56 (RA 11 32 46 Dec +52 56 28), you’re going to need major aperture and excellent skies to even see a hint of this quintuplet.

Thanks to the photographic magic of Dietmar Hager of Austria, we’re able to enjoy this cosmic portrait. Using a 9″ TMB refractor, the image was captured with a SXV H16 CCD camera and processed with AstroArt Software, Maxim DL and Registax. When Dietmar isn’t busy being a trauma surgeon, he certainly takes outstanding astrophotos and is a member of the MRO imaging team. We thank him for sharing!

9 Responses

  1. Awesome galaxy image. So well processed.

  2. John -- says

    Not only does Dietmar take wonderful images of galaxies, but he also recently took a wonderful shot of Vallis Alpes (see ).
    I wish more, like him, would look to (and promote) the Moon, as there are a lot of wonderful images that even small telescopes can take.
    So many today are fixated with taking images of star-points and galaxies…etc.,, that they’re forgetting about our wondeful neighbour — the Moon.
    Sorry, if I went off topic on the above article, but I had to mention Dietmar’s recent contribution t LPOD.
    John —

  3. Astrofiend (Syd, Aust) says

    “… Using a 9″ TMB refractor, the image was captured with a SXV H16 CCD camera …”

    – Equipment lust.

  4. shailendra kumar says

    i want to know more and more about universe please give me enough information at my mail.
    thank you!

  5. Member

    shailendra? Stay tuned…. As the weeks pass, if you follow the links you’ll get a surprising astronomy education. I don’t just pick these images at random. They serve lessons, too!

    And keep your eye out for great lunar images in the Weekend SkyWatcher’s Forecast during the lunar cycle! (yes, his work is awesome and he’ll be so pleased you recognized it!)

    We’ll take you from one side on the Cosmos to the other in words and pictures… 😉

  6. Sakib says

    Hey shailendra kumar, check out my website at

  7. Ignoramus says

    Great to see Chip Arp getting his due

  8. marcellus says

    NGC 3729 is listed in The Herschel 400 Objects, but NGC 3718 is not. They’ll be top priority the next time I go out.

    If any of you folks want a cool starhop adventure, try NGC 2683 an edge on galaxy in Lynx.

    Start at M44, the Beehive cluster (easy to find, always cool) then go north to Iota Cancri, a wide and easy double star with a nice color contrast, “the Spring Albireo”. Then NE to 57 Cancri, a tight little double star that can be separated at 200X. Both golden in color it reminds me of a mini Gamma Leonis. Then north to the Sigma Cancri group. Two stars here point directly towards NGC 2683. I put my finder on where I thought it would be and almost hit it dead center FOV. 2683 is an edge on spiral galaxy that reminds me of NGC 4565. It is quite bright and very pretty.


  9. Member

    nice call, marcellus!! 8D

Comments are closed.
