Since the Apollo program wrapped up in the early 1970s, people all around the world have dreamed of the day when we might return to the Moon, and stay there. And in recent years, however, that actual proposals for a lunar settlement have begun to take shape. As a result, a great deal of attention and research has been focused on whether or not the Moon has indigenous sources of water.
Thanks to missions like
Chandrayaan-1
and the
Lunar Reconnaissance Orbiter
(LRO), scientists know that there are vast amounts of surface ice on the Moon. However, according to a
new study
, researchers from Brown University have found evidence of widespread water within volcanic deposits on the lunar surface. These findings could indicate that there are also vast sources of water within the Moon's interior.
For their study - titled "
Remote Detection of Widespread Indigenous Water in Lunar Pyroclastic Deposits
" - Brown researchers
Ralph E. Milliken
and
Shuai Li combined satellite data with new thermal profiles to search for signs of water away from the polar regions. In so doing, they addressed a long-standing theory about the likelihood of water in the Moon's interior, as well as the predominant theory of how the Moon formed.
[caption id="attachment_115427" align="aligncenter" width="580"]
Lunar Crater as imaged by NASA's Moon Mineralogy Mapper. Credit: SRO/NASA/JPL-Caltech/USGS/Brown Univ.
[/caption]
As noted, scientists have known for years that there are large amounts of frozen water in the Moon's polar regions. At the same time, however, scientists have held that the Moon's interior must have depleted of water and other volatile compounds billions of years ago. This was based on the widely-accepted hypothesis that the Moon formed after a Mars-sized object (named
Theia
) collided with Earth and threw up a considerable amount of debris.
Essentially, scientists believed that it was unlikely that any hydrogen - necessary to form water - could have survived the heat of this impact. However, as of a decade ago, new scientific findings began to emerge that cast doubt on this. The first was a
2008 study
, where a team of researches (led by Alberto Saal of Brown University) detected trace amounts of water in samples of volcanic glass that were bought back by the
Apollo 15
and
Apollo 17
missions.
This was followed by a
2011 study
(also from Brown University) that indicated how crystalline structures within those beads contained as much water as some basalt mineral deposits here on Earth. These findings were particularly significant, in that they suggested that parts of the Moon's mantle could contain as much water as Earth's. The question though was whether these findings represented the norm, or an anomaly.
As Milliken, an associate professor in Brown's
Department of Earth, Environmental, and Planetary Sciences
(DEEPS) and the co-author on the paper, summarized in a recent
Brown press release
:
[caption id="attachment_74107" align="aligncenter" width="580"]
A false colour composite of the distribution of water and hydroxyl molecules over the lunar surface. Credit: ISRO/NASA/JPL-Caltech/Brown Univ/USGS
[/caption]
To resolve this, Milliken and Li consulted orbital data to examine lunar volcanic deposits for signs of water. Basically, orbiters use spectrometers to bounce light off the surfaces of planets and astronomical bodies to see which wavelengths of light are absorbed and which are reflected. This data is therefore able to determine what compounds and minerals are present based on the absorption lines detected.
Using this technique to look for signs of water in lunar volcanic deposits (aka. pyroclastic deposits), however, was a rather difficult task. During the day, the lunar surface heats up, especially in the latitudes where volcanic deposits are located. As Milliken
explained
, spectronomers will therefore pick up thermal energy in addition to chemical signatures which this can throw off the readings:
To correct for this, Milliken and Li constructed a detailed temperature profile of the areas of the Moon they were examining. They then examined surface data collected by the
Moon Mineralogy Mapper
, the spectrographic imager that was part of India's Chandrayaan-1 mission. They then compared this thermally-corrected surface data to the measurements conducted on the samples returned from the Apollo missions.
[caption id="attachment_136549" align="aligncenter" width="580"]
Colored areas indicate elevated water content compared with surrounding terrains. Yellows and reds indicate the richest water content. Credit: Milliken lab/Brown University
[/caption]
What they found was that areas of the Moon's surface that had been previously mapped showed evidence of water in nearly all the large pyroclastic deposits. This included the deposits that were near the Apollo 15 and 17 landing sites where the lunar samples were obtained. From this, they determined that these samples were not anomalous in nature, and that water is distributed across the lunar surface.
What's more, these findings could indicate that the Moon's mantle is water-rich as well. Beyond being good news for future lunar missions, and the construction of a lunar settlement, these results could lead to a rethinking of how the Moon formed. This research was part of Shuai Li's - a recent graduate of the University of Brown and the lead author on the study - Ph.D thesis. As he
said of the study's findings
:
What's more, Li indicated that lunar water that is located in volcanic deposits could be a boon for future lunar missions. "Other studies have suggested the presence of water ice in shadowed regions at the lunar poles, but the pyroclastic deposits are at locations that may be easier to access," he
said
. "Anything that helps save future lunar explorers from having to bring lots of water from home is a big step forward, and our results suggest a new alternative."
[caption id="attachment_102614" align="aligncenter" width="580"]
The blue areas show locations on the Moon's south pole where water ice is likely to exist. Credit: NASA/GSFC
[/caption]
Between NASA, the ESA, Roscosmos, the ISRO and the China National Space Administration (CNSA), there are no shortage of plans to explore the Moon in the future, not to mention establishing a permanent base there. Knowing there's abundant surface water (and maybe more in the interior as well) is therefore
very
good news. This water could be used to create hydrazine fuel, which would significantly reduce the costs of individual missions to the Moon.
It also makes the idea of a stopover base on the Moon, where ships traveling deeper into space could refuel and resupply - a move which would shave billions off of deep-space missions. An abundant source of local water could also ensure a ready supply of drinking and irrigation water for future lunar outposts. This would also reduce costs by ensuring that not all supplies would need to be shipped from Earth.
On top of all that, the ability to conduct experiments into how plants grow in reduced gravity would yield valuable information that could be used for long-term missions to Mars and other Solar bodies. It could therefore be said, without a trace of exaggeration, that water on the Moon is the key to future space missions.
The research was funded by the NASA Lunar Advanced Science and Exploration Research (LASER) program, which seeks to enhance lunar basic science and lunar exploration science.
Further Reading: Brown University
