[caption id="attachment_128401" align="aligncenter" width="900"]
The Solar and Heliospheric Observatory (SOHO) took these photos of Mercury during its last transit of the Sun on Nov. 8, 2006. Credit: NASA/ESA[/caption]
Be sure to mark your calendar for May 9. On that day, the Solar System's most elusive planet will pass directly in front of the Sun. The special event, called a transit, happens infrequently. The last
occurred more than 10 years ago, so many of us can't wait for this next. Remember how cool it was to see Venus transit the Sun in 2008 and again in 2012? The views will be similar with one big difference: Mercury's a lot smaller and farther away than Venus, so you'll need a telescope. Not a big scope, but something that magnifies at least 30x. Mercury will span just 10 arc seconds, making it only a sixth as big as Venus.
[caption id="attachment_128402" align="aligncenter" width="900"]
Two basic types of safe solar filters for telescopes: an aluminized polymer such as Baader film and a dedicated glass solar filter for a particular make and model. Credit: Bob King[/caption]
That also means you'll need a solar filter for your telescope. If you've put off buying one, now's the time to plunk down that credit card. Safe, quality filters are available from many sources including
,
,
and
.
[caption id="attachment_128404" align="aligncenter" width="577"]
Map showing Mercury's path across the Sun at three key points on May 9: transit start or ingress (left); midpoint and transit end or egress (right). Credit: Tom Ruen with additions by author[/caption]
If I might make a suggestion, consider buying a sheet of
aluminized polyester film and cutting it to size to make your own filter. Although the film's crinkly texture might make you think it's flimsy or of poor optical quality, don't be deceived by appearances.
The material yields both excellent contrast and a pleasing neutral-colored solar image. You can purchase any of several different-sized films to suit your needs either from
or on
.
Prices range from $40-90.
Nov. 8, 2006 Transit of Mercury by Dave Kodama
With filter material in hand, just
to make your own, snug-fitting telescopic solar filter. Even I can do it, and I kid you not that I'm a total klutz when it comes to building things. If for whatever reason you can't get a filter, go to Plan B. Put a low power eyepiece in your scope and project an image of the Sun onto a sheet of white paper a foot or two behind the eyepiece.
[caption id="attachment_128403" align="aligncenter" width="1008"]
World map showing where the May 9-10 Mercury transit will be visible. Universal times of the four key contacts (see below for details), mid-transit time and position angle on the Sun's limb where the planet will first appear and disappear are given at upper left. Credit: Xavier M. Jubier[/caption]
Since May 9th is a Monday, I've a hunch a few of you will be taking the day off. If you can't, pack a telescope and set it up during lunch hour to share the view with your colleagues. Mercury will spend a leisurely 7 1/2 hours slowly crawling across the Sun's face, traveling from east to west. The entire transit will be visible across the eastern half of the U.S., most of South America, eastern and central Canada, western Africa and much of western Europe. For the western U.S., Alaska and Hawaii the Sun will rise with the transit already in progress.
Time Zone Eastern (EDT) Central (CDT) Mountain (MDT) Pacific (PDT)
Transit start 7:12 a.m. 6:12 a.m. 5:12 a.m. Not visible
Mid-transit 10:57 a.m. 9:57 a.m. 8:57 a.m. 7:57 a.m.
Transit end 2:42 p.m. 1:42 p.m. 12:42 p.m. 11:42 a.m.
[caption id="attachment_128409" align="alignleft" width="322"]
Nov. 2006 animation by Hinode. Credit: NASA[/caption]
At first glance, the planet might look like a small sunspot, but if you look closely, you'll see it's a small, perfectly circular black dot compared to the out-of-round sunspots which also possess the classic two-part umbra-penumbra structure. Oh yes, it also moves. Slowly to be sure, but much faster than a typical sunspot which takes nearly two weeks to cross the Sun's face. With a little luck, a few sunspots will be in view during transit time; compared to midnight Mercury their "black" umbral cores will look deep brown.
I want to alert you to
four
key times to have your eye glued to the telescope; all occur during the 3 minutes and 12 seconds when Mercury enters and exits the Sun. They're listed below in Universal Time or UT. To convert UT to EDT, subtract 4 hours; CDT 5 hours; MDT 6 hours, PDT 7 hours, AKDT 8 hours and HST 10 hours.
[caption id="attachment_128406" align="aligncenter" width="1152"]
The black drop effect seen to good advantage during the June 2004 transit of Venus. Credit: Jan Herold[/caption]
- First contact (11:12 UT)
-
Watch for the first hint of Mercury's globe biting into the Sun just south of the due east point on along the edge of disk's edge. It's always a thrill to see an astronomical event forecast years ago happen at precisely the predicted time.
Second contact (11
:
15 UT
): Three minutes and 12 seconds later, the planet's trailing edge touches the inner limb of the Sun at second contact. Does the planet separate cleanly from the solar limb or briefly remain "connected" by a narrow, black "line", giving the silhouette a drop-shaped appearance?
This
is caused primarily by diffraction, the bending and interfering of light waves when they pass through the narrow gap between Mercury and the Sun's edge. You can replicate the effect by bringing your thumb and index finger closer and closer together against a bright backdrop. Immediately before they touch, a black arc will fill the gap between them.
[caption id="attachment_128400" align="aligncenter" width="864"]
The "black drop effect" can be reproduced by slowly bringing your thumb and index finger together. It's caused by diffraction combined with blurring from the atmosphere. Credit: Bob King[/caption]
- Third contact (18:39 UT)
-
A minute or less before Mercury's leading edge touches the opposite limb of the Sun at third contact, watch for the black drop effect to return.
- Fourth contact (18:42 UT)
-
The moment the last silhouetted speck of Mercury exits the Sun. Don't forget to mark your calendar for November 11, 2019, date of the next transit, which also favors observers in the Americas and Europe. After that one, the next won't happen till 2032.
Other interesting visuals to keep an eye out for is a bright ring or aureole that sometimes appears around the planet caused when our brain exaggerates the contrast of an object against a backdrop of a different brightness. Another spurious optical-brain effect keen-eyed observers can watch for is a central bright spot inside Mercury's black disk. Use high power to get the best views of these obscure but fascinating phenomena seen by many observers during Mercury transits.
[caption id="attachment_128408" align="aligncenter" width="864"]
NASA's Hinode X-ray telescope captured this view of Mercury silhouetted against the Sun's corona during the Nov. 2006 transit. Similar views are possible in H-alpha light should the planet pass in front of a prominence. Credit: NASA[/caption]
While I've been talking all "white light" observation, the proliferation of relatively inexpensive and portable
in recent years makes them another viewing option with intriguing possibilities. These instruments show solar phenomena
beyond
the Sun's limb, including the flaming prominences normally seen only during a total eclipse. That makes it possible to glimpse Mercury minutes in advance of the transit (or minutes after transit end) silhouetted against a prominence or nudging into the rim furry ring of
surrounding the outer limb. Wow!
One final note. Be careful never to look directly at the Sun even for a moment during the transit. Keep your eyes safe! When aiming a telescope, the safest and easiest way to center the Sun in the field of view is to shift the scope up and down and back and forth until the shadow the tube casts on the ground is shortest. Try it.
I hope the weather gods smile on you on May 9, but it they don't or if you live where the transit won't be visible, Italian astrophysicist Gianluca Masi will stream it live on his
starting at 11:00 UT (6 a.m CDT).
