Cruising the Cloud Tops of Venus With a Solar-Powered Airplane

by Nancy Atkinson on July 10, 2008

Want to stay on top of all the space news? Follow @universetoday on Twitter

With all the orbital missions at the various planets in our solar system, scientists have been able to glean an amazing amount of data to help us understand our neighboring worlds. But imagine a mission that could fly lower than orbital altitudes — actually flying in the atmosphere of another planet and closer to the surface — and imagine how much more detailed the data could be. This type of mission would be especially helpful on Venus, where the intense heat and crushing air pressure at the surface basically precludes the success of any type of lander mission. So, last year, when NASA formed a Science and Technology Definition Team (STDT) to study the concept of a flagship mission to Venus, waiting in the wings was Dr. Geoffrey Landis. For the past several years Landis and a group of scientists and engineers from NASA’s Glenn Research Center have been studying the concept of a solar-powered airplane at Venus. Landis says a small aircraft powered by solar energy could fly continuously in Venus’ atmosphere, and would be an ideal vehicle for gathering data on both the planet’s atmosphere and surface, with the ability to maneuver almost anywhere.

“There’s a lot of interest in Venus at the moment,” said Landis. “We’ve been looking at Mars quite a bit lately, and in some ways Mars is Earth’s twin, but in even more ways, Venus is Earth’s twin. So we learn a lot about Earth by studying Venus.”

A solar powered airplane has been a long-time interest for Landis. “I spent a lot of time in college building model airplanes, so the idea of flying an airplane on Venus sounded very interesting to me,” he said.

Since 2000, Landis and his team have been studying this concept, and Landis recently presented their findings to NASA’s STDT for Venus. “I’ve been trying to drum up enthusiasm for the things we’ve done,” he said. The main work the group has done so far has been focusing on the airplane itself, verifying that the concept is actually going to work.

“We’ve done a thorough design study to determine if there are any showstoppers,” said Landis. “We don’t think there are. We think it’s a very doable project.”

The airplane would have to fold up to fit inside a small aeroshell for a “Discovery” class scientific mission. After arriving at Venus the craft would deploy from the aeroshell, unfold and begin gliding through the atmosphere. With solar cells covering the entire surface, the airplane would fly strictly on solar power, not needing fuel. The team has come up with a foldable design that has a wingspan of 9 meters and a length of just under 7 meters.

Surprisingly, the density of Venus’ atmosphere shouldn’t be a problem for a solar airplane mission. “At the altitudes we’ll be flying, it would be like flying at moderate altitudes on Earth,” said Landis. “Venus is actually a very easy planet to fly on. Interestingly, the problem on Venus is the wind. It turns out it’s a very windy planet, and we would like to be able to keep our solar airplane flying underneath the sun, so we have to fly faster than the wind so we can stay in the sunlight. If we can do that we can basically fly forever.”

The craft would have to be capable of sustained flight at or above the wind speed, about 95 m/sec at the cloud-top level, 65 to 75 km above the surface. For exploration at lower altitudes, the aircraft could glide down for periods of several hours and then climb back to higher altitudes, allowing the cloud layers to be probed. But the airplane would have to be in sunlight for a majority of the time. The team’s analysis of a flight using battery storage shows that it wouldn’t work to keep the aircraft aloft on battery power during the passage across the night side of the planet.

As far as the science that can be gleaned from a solar-powered airplane at Venus, Landis’ team has primarily envisioned a mission to study Venus’ atmosphere. However, they’ve also looked at using it for a radar mission, and in particular if two airplanes could be used, one could be a transmitter and the other a receiver to do what’s called “bistatic radar” where you vary the angle between the transmission and the receiver to provide additional information about the planet. But mainly, an airplane flies much closer to the surface than an orbiting spacecraft, to gather greater detailed information about the planet.

The current focus of Landis’ team has been deciding what type of science could be done, and how it could best be achieved. “What we’ve been doing lately is just studying Venus and asking ourselves, what do we want to do,” said Landis. “Is an airplane the right thing? We’ve also been looking at airships. You can make a zeppelin fly at the planet Venus, which has both advantages and disadvantages over an airplane, so we’re asking ourselves, at what altitude in the clouds do we want to fly — above, below, or in the clouds — and what science we can do? The very hard part on Venus is flying low. It’s very easy to fly high, but the lower you could fly, the better the science you could accomplish. But flying low will be tricky.”

Interestingly enough, last year, students from Boston University also conducted a design study of a solar airplane at Venus, and they looked at the design that Landis’ team had come up with. The BU students also concluded such as mission was quite feasible. “They looked at the basic airplane design: Can you actually fly on Venus? We looked at things like, could you fold it up into the aeroshell, and how would it be deployed, etc.,” Landis said. “We found this second study to be a very useful sanity check for us, that an independent group of people looked at our ideas, and said that no, this isn’t out of the question.”

So, when could a solar-powered airplane mission be ready to fly over Venus? “It depends on how hard the mission you want to do is,” said Landis. “If you’re doing a simple solar airplane mission, we’ve shown that there aren’t any technology showstoppers in the airplane itself, so I think it’s something we could do in the near term, by the next decade. But the more difficult the mission you’re interested in, say if you’re interested in flying low or in the polar regions, places where it’s harder to fly, we’d have to back off and think about what the correct type of vehicle would be.”

This paper discusses more information about the Venus Solar Powered Airplane

About

Nancy Atkinson is Universe Today's Senior Editor. She also works with Astronomy Cast, and is a NASA/JPL Solar System Ambassador.

Astrofiend July 10, 2008 at 5:07 PM

I personally can’t wait until we’re flying around other planets. Awesome.

marcellus July 11, 2008 at 12:29 AM

Venus has way too much atmosphere. I’ve read that the surface pressure on Venus is equal to 90 times the Earth’s surface pressure. Essentially equivalent to six tenths of a mile beneath the ocean’s surface.

It woud be incredibly cool to have a sustainable solar powered airplane in the atmosphere of Venus. It would be like having a cheaper, closer, long lasting space mission like Cassini around Saturn, or the Mars Rover missions.

Awesome!

alandee July 10, 2008 at 8:32 PM

I still get a buzz out of flying around our planet !
I love the idea of a dirigible flying around another planet even more though, you have a large stable platform, that, unless it is hit by something will never crash, and can hover over areas of interest, the whole top can be covered in solar panels… the list of things I want to see happen before I die is endless ..

Qev July 10, 2008 at 10:09 PM

I wonder if we could work out a Jovian dirigible… wouldn’t that be something? :)

James July 10, 2008 at 10:55 PM

If it works out, yeah, I wonder what other planets we could extend the idea to. We’d get so much information on all the planets we send these things to!
Jupiter seems like it’d never work out for some reason. Just the density of the atmosphere and the strength of the gravity there…but I’m no airplane physicist, so who knows.

Question: Why is the sky blue in those pictures? I thought Venus had no atmosphere, and was instead getting blasted with the solar wind (causing that huge tail that extends almost to Earth’s orbit).
Wouldn’t the sky be a different color during the day? If so, I wonder what.

Eric Ramos July 11, 2008 at 7:14 AM

hmmm….unfolding those wings frontally as those illustrations depict while plunging downwards will be almost impossible after gaining certain speed.. I guess they should deploy edgewise at 180° from each other and then with some help of a tail chute or friction slowing gadget maintain low velocity to then allow the wings to twist 90°, eject the chute and level off.

neoguru July 11, 2008 at 7:15 AM

Venus would be tough! Concentrated sulfuric acid is abundant in the atmosphere and would wreak havoc on almost any material the aircraft is made of. A real challenge!

Rafael July 11, 2008 at 1:00 PM

I’m a basic space enthusiast here. The idea of hovering over the terrain of Mars, Europa, Titan is too exciting for words. I love Venus, but assuming we couldn’t get under the Venusian cloud tops – a mission like the above would only be to see if we could accomplish it. Some science, but no real fun seeing cloud tops.

Colin July 12, 2008 at 1:07 AM

Dibs on opening the Tibanna gas mine on Cloud City.

Silver Thread July 12, 2008 at 9:13 AM

Ahh Colin you Stole my Thunder!! :) I was thinking the exact same thing. The programming for an auto pilot on such an aircraft will need to be fairly complex but I see this idea as having incredible merit.

Geoffrey A. Landis July 12, 2008 at 10:34 PM

“hmmm….unfolding those wings frontally as those illustrations depict while plunging downwards will be almost impossible after gaining certain speed..”
Yep. It’s not shown in those images, but there’s a parachute to slow us down. This website http://www.grc.nasa.gov/WWW/5000/pep/photo-space/venus-mission-design.htm has a link to an animation of a movie showing some of our work on both the airplane and Venus landers.

Van July 12, 2008 at 11:46 PM

If solar can do this, when will it be economical to recharge electric cars with solar while I work? And it hit 100 degrees F again here in Texas – solar powered A/C would sure cut down on a lot of carbon dioxide!

Nice of Venus to have such a long day – at the equator of my planet, you have to fly over 1000 mph to stay in the sun!

alphonso richardson July 17, 2008 at 2:51 AM

Geoff,

just been to the NASA site – cool. Also read the paper.,
Seems like an awful lot of work, but if it means it’s possible to send probes that last more than a few minutes/hours before being crushed/fried/corroded to death, then I’m sure it’ll be worth it.

Sally August 26, 2008 at 8:30 AM

This was a very good passage to read and was very interesting.THANK YOU

MyPicture and friend February 23, 2009 at 12:55 AM

nice post, friend.please come to my blog to see MY picture and friend
